NETGEAR RBR20 Orbi Mesh WiFi Router User Guide

1

2

Set Up Your Orbi

Router and Satellite

Satellite Ring LED

Sync Colors

Aſter the satellite is powered on, the

satellite’s ring LED lights white while

the satellite attempts to sync with the

router. Then the ring LED lights one of the

following colors for about three minutes

and then turns off:

Web Browser Setup

1. Unplug your modem and remove and

reinsert the backup battery if it uses

one.

2. Plug the modem back in.

3. Use the included Ethernet cable to

connect your modem to the yellow

The connection between the

Internet port on your router.

satellite and router is good.

Blue

Note: If you want to connect your

router to an existing gateway, we

recommend that you turn off your

existing gateway’s WiFi.

Quick Start Guide

The connection between the

Set up your router and satellite with the

NETGEAR Orbi app or a web browser.

satellite and router is fair.

Consider moving the satellite

closer to the router.

Amber

4. Plug in your router.

NETGEAR Orbi App Setup

1. Scan a QR code or search for NETGEAR

Orbi in the Apple App Store or Google

Play Store.

The Power LED on the back of the

router lights green. If the Power LED

does not light, press the Power On/

Off button.

The satellite failed to sync

with the router. Move the

satellite closer to the router.

Magenta

2. Download and launch the NETGEAR

Orbi app on your mobile device and

follow the prompts.

5. Wait for the router’s ring LED to light

white.

6. Place your satellite, plug it in, and wait

for the satellite’s ring LED to light blue.

Note: If the ring LED still lights magenta

aſter about one minute, press the Sync

button on the router and on the satellite.

If the satellite syncs with the router, the

satellite’s ring LED lights white, then lights

blue to indicate a good connection, and

then turns off.

If the satellite’s ring LED lights amber

or magenta, move the satellite closer

to the router. For more information,

see Satellite Ring LED Sync Colors.

7. Connect your computer or mobile

device to the router or satellite with

Ethernet or WiFi:

•

Ethernet. Use an Ethernet cable

to connect a computer to the

router or satellite.

•

WiFi. Use the WiFi network name

(SSID) and password on the router

or satellite label to connect.

8. Launch a web browser, visit

orbilogin.com, and follow the prompts.

If a login window opens, enter the user

name and password. The user name

is admin and the default password is

password.

January 2018

https://manual-hub.com/



(1 votes, average: 5.00 out of 5)

Loading...

• ALL WI-FI INSTRUCTIONS & USER MANUALS
• NETGEAR

NETGEAR RBR20 Orbi Mesh WiFi Router User Guide Overview

Summary of Contents

• Page 1: Set up your Orbi router and satellite with the NETGEAR Orbi app or a web browser. After the satellite is powered on, the satellite’s ring LED lights white while it attempts to sync with the router. The connection between the satellite and router is good if the ring LED lights blue. If you want to connect your router to an existing gateway, we recommend that you turn off your existing gateway’s WiFi. Plug in your router and wait for the router’s ring LED to light white. Place your satellite, plug it in, and wait for the satellite’s ring LED to light blue. If the ring LED still lights magenta after about one minute, press the Sync button on the router and on the satellite. Connect your computer or mobile device to the router or satellite with Ethernet or WiFi. Use an Ethernet cable to connect a computer to the router or satellite. Use the WiFi network name (SSID) and password on the router or satellite label to connect. Launch a web browser, visit orbilogin.com, and follow the prompts. The user name is admin and the default password is password.
• Page 2: Package contents include the Orbi router and Orbi wall plug satellite. The Orbi router model is RBR20 and the satellite model is RBW30. Ensure to use only official NETGEAR support resources for assistance. Refer to the regulatory compliance document before connecting the power supply. The power adapter may vary by region. The device features a power on/off button, power LED, sync button, internet port, power connector, reset button, and ethernet port. For the current EU Declaration of Conformity, visit the designated NETGEAR webpage. Access the document in Canadian French if the product is sold in Canada. Visit the NETGEAR support website for product registration and downloads. Join the NETGEAR community for additional help and resources. The ring LED is not shown in the image provided. Ensure to check the regulatory compliance information for further details.
