TP-Link Wireless 4G LTE Telephony Router Installation Guide

1

2

1. Connect the Hardware

Router

a. Install the antennas

and position them

upwards.

Quick Installation Guide

Wireless 4G LTE Telephony Router

d. Connect your landline

phone to the RJ11

port (PHONE port).

c. Connect the power

adapter and turn

on the router.

b. With the gold contacts

facing down, insert the

nano SIM card into the

slot until you hear a click.

Images may differ from actual products.

©2020 TP-Link 7106509090 REV1.0.0

2. Verify the Hardware Connection

3. Enjoy the Internet

4. Customize the 4G LTE Router

Check the following LEDs’ status. If the Internet LED

connected to the internet successfully.

is on, your router is

Wired

1. Make sure your computer is connected to the router (wired or wireless).

2. Launch a web browser and type in http://tplinkmodem.net or

http://192.168.1.1. Create a new password for future logins.

Connect your computer to the router's LAN port via an Ethernet cable.

Wireless

Note: If the login page does not appear, please refer to Q1 of Need Help? in this guide.

Power

On

Internet

On

Wi-Fi

On

a. Find the SSID (network name) and wireless password printed on the label at the

bottom of the router.

http://tplinkmodem.net

Note: If the Internet LED does not turn on, please refer to Need Help? > Q2 on the back page.

New Password

Note: For a dual-band router, you can find two default SSIDs. Choose one to join the Wi-Fi.

Low

Middle

High

For better internet connection, make sure 2 or 3 bars of the Signal Strength LED

are lit. Otherwise, try relocating the router to a spot that may receive a stronger

mobile network signal, such as near a window.

Confirm Password

Let’s Get Started

3. Follow the step-by-step instructions of the Quick Setup to complete the initial

b.

Click the network icon of your computer or go to Wi-Fi settings of your smart

device, and then select the SSID to join the network.

configuration.

Note: The router can also be used (or configured) in Wireless Router Mode for

DSL/Cable connections. For more advanced configurations, please refer to the user

guide on TP-Link official website at www.tp-link.com.
