Start Guide

ICR-2701, ICR-2734, ICR-2834

VIEW FULL SCREEN PDF MANUAL

General	Details
Name	ADVANTECH ICR-2701 Engineering Portal Cellular Router User Guide
Make	Advantech
Language	English
Filetype	PDF (Download)
File size	0.18 MB

Download PDF

(1 votes, average: 5.00 out of 5)

Loading...

• Advantech
• ALL WI-FI INSTRUCTIONS & USER MANUALS

ADVANTECH ICR-2701 Engineering Portal Cellular Router User Guide Overview

Summary of Contents

• Page 1: Start guide for ICR-2701, ICR-2734, ICR-2834.
• Page 2: Start guide Safety instructions Use the router in compliance with national and international law and any special restrictions. To avoid injury and/or damage, observe relevant provisions and standards. Use only the original accessories as recommended. Unauthorized modifications can result in router damage and/or violation of regulations. Do not open the router. Caution: small children can swallow the SIM card. Do not exceed the defined voltage when connecting to a power supply. Protect the router against dust, moisture, and high temperature. Do not use the router at petrol filling stations. Create a copy or backup of the essential settings stored in the memory of the router.
• Page 3: Start guide Product disposal instructions The WEEE directive was introduced to ensure that electrical/electronic products are recycled using the best available recovery techniques to minimize the impact on the environment. This product contains high-quality materials and components which can be recycled. At the end of its life, this product must not be mixed with other commercial waste for disposal. The device contains a battery. Remove the battery from the device before disposal. The software in this device uses various pieces of open-source software governed by several licenses. The list of components together with complete license texts can be found on the device itself. This is a written offer valid for three years since the device purchase, offering any third party a complete machine-readable copy of the corresponding source code. The device manufacturer grants the right to use debugging techniques and making customer modifications of any executable linked with an LGPL library for its purposes.
• Page 4: Start guide Before applying power to the router, connect all the components you need for your applications. Do not run the router without an antenna connected to the main antenna connector. The energy from the transmission is effectively reflected by the open end and can damage the equipment. Use SMA connectors to connect the cellular antennas to the router. First, connect the main antenna to the ANT connector. Next, connect the second diversity antenna to the DIV connector to improve the quality and reliability of a wireless link.
• Page 5: Start guide Disconnect the router from the power supply before handling the SIM card. The SIM card reader for two Mini SIM cards is located on the router’s front panel under a metal cover. If you intend to use this device to communicate over a cellular network, please place an activated data-provisioned SIM card into the SIM card slot. A cross-shaped screwdriver is necessary to release the SIM card cover. Unscrew two screws holding the metal plate, push it up, and push your SIM card upside down into the SIM slot until it clicks into place. You can install two SIM cards simultaneously to utilize the SIM card switching feature.
• Page 6: Start guide The router requires an external DC power supply. The DC voltage required is between +9 and +48 V DC. The router has built-in protection against reverse polarity without signaling. Connect the power supply cable to the PWR connector on the front right panel of the router. For an initial configuration made in a web browser, connect a PC by an Ethernet cable to the default LAN interface. By default, this interface has the following configuration: ETH0 LAN port (default). Default setting: DHCP server. Connect your PC to this port to get the IP address: 192.168.1.1. NetMask: 255.255.255.0.
• Page 7: Start guide You can use a web browser running on your PC to access the router web interface for monitoring, configuration, and administration. Connect the PC to the default LAN interface to access the router interface by entering https://192.168.1.1 in a web browser. Usage of the HTTPS protocol for secure communication over the network is required. There is just the root user account created on the router by default. Log in to the web interface using the root user and the default password found on the product label. It is strongly recommended to change the default password after the first login for security reasons. Regularly updating the router’s firmware to the latest version is highly recommended for security. Downgrading the firmware or uploading firmware intended for a different device may cause malfunction. Your router has been pre-installed with the WebAccess/DMP client, which is activated by default. The activated client periodically uploads router identifiers and configuration to the WebAccess/DMP server.
• Page 8: Start Guide Restoring and backing up the router configuration The default factory settings will replace the current configuration if you reset the router. We recommend you back up the router configuration before resetting the device. You can restore the default router configuration once the router boots up and the PWR LED starts blinking. To restore, press the RST button on the router’s front panel for more than 4 seconds. After pressing this button, all settings reset to the default values, and the router will reboot. Support All product-related manuals, documents, and software can be found and downloaded on the website. We declare that the radio equipment type ICR-2734 and ICR-2834 comply with Directive Radio Equipment Regulations 2017. The full text of the EU Declaration of Conformity is available at the specified internet address.
