AKYPACH A2 Wood Router Tool Compact Trim Router Instruction Manual

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

AKYPACH

Speed

Number

10,000 rpm (Minimum)

16,000 rpm

1

2

3

4

5

6

22,000 rpm

28,000 rpm

34,000 rpm

40,000 rpm (Maximum)

Installing and Using the Accessory Dust Port:

The AKYPACH Wood Router is supplied with a dust extraction port. It is designed

to snap into the base and allow you to hook it up to a vacuum source to remove

the dust and chips that are created during the routing operation.

The dust port has a pin on the inside near the extraction port that fits into the hole

in the base. The dust port is secured to the base with the small thumbscrew which

threads into the base on the opposite side of the port as shown in the diagram

below.

- 9 -
