Installing and Using the Straight Edge Guide:

The edge guide is used for making straight cuts, grooves or following an edge with

a bit that does not have a guide bearing.

Attach the guide plate to the straight guide with the bolt and wing nut. Make sure

to position the straight guide with the guide fence positioned downward as shown

in the diagram.

Secure the straight edge guide to the router base using the clamping screw on

the router base.

Loosen the wing nut on the straight edge guide and adjust the distance between

the router bit and the straight guide to the desired position.

Tighten the wing nut to secure the straight edge guide at the correct distance.

When making the cut, move the router with the straight guide firmly against the edge

of your stock.

If the desired location of the cut is greater than the capacity of the straight edge

guide, refer to the previous page for the instructions“Cutting a Straight Line using

a Straight Edge Guide”.

Making a Circle Cut:

Cutting circles between a minimum radius of 2-3/4”and maximum radius of 6-11/16”

can be accomplished with the straight edge guide.

You have to assemble the guide as shown with the straight edge positioned upward,

and use a nail to act as a pivot pin for the guide to rotate around. Adjust the size

of the circle and lock in place using the wing nut.
