NETGEAR PR60X Pro 10G Multi Gigabit Dual WAN Pro Router Installation Guide

1

2

After starting up and during setup, the PR60X’s LEDs can light in these colors:

Step 1. Connect to a modem and power

You can manage the router through the local device UI while connected to the local LAN,

or remotely using NETGEAR Insight mode (subscription required).

In a standard setup you connect the PR60X directly to a modem or gateway, which

provides Internet connectivity to the PR60X. Alternatively, you can use an existing LAN

connection from another router that can provide Internet connectivity to the PR60X.

Step 3. Select the PR60X management method

Power LED

Solid amber: The PR60X is starting. (Solid amber lasts for about

one minute.)

SFP+ LED

for 10G

LAN4 port

Solid green: The link is up.

For information about the link speed, see the PR60X device user

interface (UI), the Cloud Portal dashboard, or the Insight app.

You can configure and manage your PR60X router locally, or you can use NETGEAR

Insight remote management, which offers additional features and add-on services that are

not available in standalone mode.

Blinking amber: The firmware is being loaded while the PR60X is

starting or the firmware is being updated.

Off: No link is established.

Installation Guide

Your new Insight-manageable device comes with Insight included, so all you have to do

is register your router with your MyNETGEAR account to have the Insight subscription

automatically activated. For more information, visit the following pages:

Solid green: The PR60X is ready.

1. Unplug the modem or gateway’s power.

Step 2. Log in to connect to the Internet

If it uses a battery backup, remove the battery.

Internet

LED

Blinking amber: The Internet connection is in the process of

being set up.

10G/Multi-Gigabit Dual WAN Pro Router with

Insight Cloud Management

Model PR60X

•

•

netgear.com/business/services/insight/subscription/

kb.netgear.com/000061848/

2. Using an Ethernet cable, connect the modem to the yellow WAN1 port on the PR60X.

NOTE: Before you can select a management method or use Insight to manage the

PR60X, you must log in over a web browser to the device UI of the PR60X and set up

the PR60X’s Internet connection.

NOTE: If you use a setup with a LAN connection from another router, connect the

LAN cable from the other router (or from a switch that is connected to the other

router) to the yellow WAN1 port on the PR60X.

Solid green: The Internet connection is established.

Solid amber: No Internet connection is established.

Off: No link is established on the WAN1 port.

To configure and manage the PR60X, use one of the set up methods in this table.

1. Locate your Internet service provider (ISP) configuration information.

3

.

P

l

u

g

i

n

a

n

d

t

u

r

n

o

n

t

h

e

m

o

d

e

m

o

r

g

a

t

e

w

a

y

.

A. Cloud Portal/remote setup

B. Insight app/remote setup

C. Local setup

NETGEAR Insight Cloud Portal: See

A. Use the Cloud Portal to add the PR60X to NETGEAR Insight

Front view PR60X

2. Connect a computer with an Ethernet cable to a LAN port on the PR60X.

If it uses a battery backup, insert the battery before you turn it on.

4. Power on the PR60X and check that the Power LED and Internet LED are lit.

For information on LED status, see the table in the following panel.

You can use LAN port 1, 2, or 3. The computer must be configured as a DHCP client

so that it can receive an IP address from the PR60X. (For most computers, the DHCP

client is enabled by default.)

NETGEAR Insight app: See

B. Use the Insight app to add the PR60X to NETGEAR Insight

Cloud LED

Off: The PR60X functions in Standalone mode or, if deployed in

Insight mode, it is not connected to the Insight Cloud.

Web browser: See

C. Configure the PR60X locally in a web browser

Solid blue: The PR60X functions in Insight mode, and is

connected to the Insight cloud.

NOTE: If you configure a WiFi access point and connect it directly to a LAN port on

the PR60X, you can also use a WiFi connection to set up the PR60X. The PR60X itself

does not provide WiFi capability nor Power over Ethernet (PoE), so, in such a setup,

you must use a power supply or PoE switch to power the access point.

Sample connections

Rear view PR60X

Port LEDs

for 2.5G

ports:

Left LED solid amber: The port detects a speed of 2.5 Gbps.

Left LED off: The port detects a speed of 1 Gbps or 100 Mbps.

Right LED solid green: The port link is up but idle.

NOTE: If you require remote management access, you must select one of the Insight

setup methods. If you only want to manage the router locally, you can select local setup.

You cannot use Insight setup and local setup interchangeably.

P

R

6

0

X

2.5G

Internet

3. Launch a web browser and enter https://routerlogin.net in the address field (this is

Modem

the same as https://192.168.1.1).

WAN1

LAN1

LAN2

LAN3

WiFi clients

2.5G

Your browser might display a security warning because of the self-signed certificate

on the PR60X, which is expected behavior. You can proceed, or add an exception for

the security warning. For more information, see kb.netgear.com/000062980/.

PoE switch

Right LED blinking green: The port is processing traffic.

Package contents

Computer

4. On the Log In page, enter the default admin password, which is password.

The Setup Wizard starts.

•

•

•

•

•

•

NETGEAR PR60X router

AC power cable (varies by region)

Ethernet cable

Port LEDs

for 10G

port:

Left LED solid amber: The port detects a speed of 10 Gbps,

5 Gbps, or 2.5 Gbps.

2.5G

Server

2.5G

2.5G

5. Follow the prompt in the Setup Wizard to connect to the Internet.

Access

point

Left LED off: The port detects a speed of 1 Gbps or 100 Mbps.

2.5G

Access

point

The Setup Wizard searches your Internet connection for servers and protocols to

determine your Internet configuration.

LAN5

WAN2

Rack-mount kit

Right LED solid green: The port link is up but idle.

This router is designed for indoor use only. If you want to connect it to a device located

outdoors, the outdoor device must be properly grounded and surge protected, and

you must install an Ethernet surge protector inline between the router and the outdoor

Rubber feet for desktop or table installation.

Installation guide

Right LED blinking green: The port is processing traffic.

6. You are also prompted to do the following:

a. Set a new admin password for local login, and set security questions and answers.

device. Failure to do so can damage the router.

b. If a new firmware version is available, follow the prompts to update the firmware.

WARNING: Before connecting this router to outdoor cables or devices, see

After you update the firmware, the PR60X restarts.

kb.netgear.com/000057103/ for safety and warranty information.

June 2023

When the PR60X connects to the Internet, the Internet LED lights solid green.
