LANCOM SYSTEMS 1800EF-4G High Availability Networking Via Fiber Router Owner’s Manual

1

2

Mounting & connecting

➀

➀

➁

➂

➃

➄

➅

➆

➇

LTE- / 4G antenna connectors

SFP interface

Insert a suitable LANCOM SFP module (e.g. 1000Base-SX or

1000Base-LX) into the SFP port. Choose a cable compatible with the

SFP module and connect it as described in the SFP module’s mounting

instructions www.lancom-systems.com/SFP-module-MI.

➀

➁

➄

Hardware Quick Reference

Screw the supplied mobile radio antennas to the appropriate connectors.

Antennas may only be attached or replaced when the device is switched

off. Mounting or dismounting while the device is switched on may

destroy the 4G modules!

LANCOM 1800EF-4G

SFP module and cable to be connected to it are not included.

Micro SIM card slot

Slide the SIM card into the SIM card slot using the marker to ensure that

the card is the right way round. Ensure that the SIM card clicks into place

on insertion.

To remove the card from the device, press the card lightly into the

device. Let go to release the SIM card from the slot.

USB interface

Connect a USB data medium or a USB printer to the USB interface.

(cable not supplied)

➅

➆

➇

The SIM card may only be inserted or removed when the device is

switched off. Inserting or removing while the device is switched on may

destroy the 4G modules!

Serial USB-C configuration interface

A USB-C cable can be used for optional configuration of the device on

the serial console. (cable not included)

Ethernet interfaces

Use the cable with the kiwi-colored connectors to connect one of the

interfaces ETH 1 to ETH 4 to your PC or a LAN switch.

➂

➃

Power supply connection socket

Use only the supplied power adapter!

WAN interface

Use the cable with the green connectors to connect the WAN interface

to your WAN modem.

Before initial startup, please make sure to take notice of the information regarding the intended use in the enclosed

installation guide!

Please observe the following when setting up the device

→ When setting up on the table, use the enclosed self-adhesive rubber pads, if applicable.

→ Do not rest any objects on top of the device and do not stack multiple devices.

→ Keep all ventilation slots of the device clear of obstruction.

→ Rack installation with the optional LANCOM Rack Mount / Rack Mount Plus

(separately available)

i

Operate the device only with a professionally installed power supply at a nearby power socket that is freely

accessible at all times.

The power plug of the device must be freely accessible.

Please note that support for third-party accessories is not provided.
